Allen Bradley 284-PWRM29G-M3

The Allen Bradley 284-PWRM29G-M3 is a power module from Rockwell Automation, part of its industrial automation control product line. Hanyite has enjoyed significant sales in China and received widespread acclaim. Hanyite has a particularly strong customer base in countries like India and Russia, particularly in Europe and the United States. Hanyite offers high-quality supply and first-class service. With established supply and sales channels and a strong team of talented individuals, we are committed to providing top-notch service anytime, anywhere, and contributing to your business success.

Application scenarios

Allen Bradley 284-PWRM29G-M3 is mainly used in industrial automation applications, such as manufacturing production lines, intelligent warehousing and energy management. It is required to operate stably in an ambient temperature range of -20℃ to 60℃.

Precautions

For the precautions of Allen Bradley 284-PWRM29G-M3, we mainly focus on installation precautions and operation precautions. When installing, the most important thing is to ensure that the input and output wiring is firm. Because the current of 29A is not small, loose wiring will generate a lot of heat and pose a fire risk. At the same time, leave sufficient space for heat dissipation for it and do not stack other heat-generating devices around it. When in operation, what needs to be prevented is overload. Although it has a protective function, working at full load for a long time will shorten its lifespan. Therefore, we suggest that you reserve a power margin of 20% to 30% when selecting the model. This is the most effective preventive measure.

Application requirements

The power cord of Allen Bradley 284-PWRM29G-M3 must match the input/output voltage and current specifications of the module to avoid overload or poor contact. The input voltage range is 10 to 31.2 VDC, with a nominal input voltage of 24 VDC. It supports 12/24 VDC potting current input. The current consumption is 120 mA at 5.1 VDC and 2 mA at 24 VDC. The total power rating of the backplane is 0.66 W. The maximum current in the off state specification is 2.27 mA and the maximum voltage is 5 V. The power supply requires 24 VDC (±10%), with low power consumption. Operating temperature: 0-60°C, storage temperature: -40-85°C, relative humidity: 5%-95% (no condensation). In damp, dusty or strong electromagnetic interference environments, please choose waterproof and dustproof (IP65 or higher) or shielded cables.
